Type A & C Solar Barricade Light (Amber)-trafficsafetywarehouse.com

Type A & C Solar Barricade Light (Amber)

This barricade light features the brightest LED optic lens which produces 20% more light output than competitive brands. It can be used with many types of barricades, traffic barrels, safety cones, and delineators. This light is a combination Type A and Type C light and is for nighttime use. Type A classification is met with double-sided flashing lights to warn of hazards, while Type C classification is met with double-sided steady burn lights that are typically used to delineate the edge of a roadway.

Features:

Amber polycarbonate double-sided lens rotates 90° for easy adjustment to any angle.
Visual distance for more than 200 yards.
Light pattern: Steady - Flash - Close.
Working time over 600 hours.
Solar rechargeable Ni-Cad batteries installed.
Automatic daytime shut off prolongs battery life. (For nighttime use only.)
Withstands heavy impacts and harsh weather conditions.
Rechargeable batteries included inside solar panel. Base is empty by design. See instructions below for charging and operation.
Meets MUTCD Standards.

Operating Instructions:

Important First Time Use Note: Place solar barricade light outside for 3 to 4 days to allow the batteries to fully charge.
There is no on/off switch. Light automatically turns on when there is no daylight reaching the solar panel.
Each light has three functions: Steady On, Flash, and Close.
When exposed to daylight, the light will shut off and you will NOT be able to set it or completely shut it off (Close). This is a safety feature that ensures no tampering or accidental shut off during the daytime.
To adjust the light flash pattern during the day, completely cover the solar panel and push the switch with included pin or a paperclip. As you push the switch with the pin, the light will cycle through the three options: steady on, flash, and close (completely off).

Includes:

Component	Quantity per single light	Quantity per case of 12
Barricade light	1	12
Tamper proof bolt	1	12
Push pin (to change light function)	1	12
Wrench	0	1

Important First Time Use Note:
Place solar barricade lights outside for 3 to 4 days to allow the batteries to fully charge.

Specifications:

Dimensions	10-1/2" L x 7" W x 3-1/2" D
Weight	1.7 lbs
Material (case)	polypropylene
Material (lens)	polycarbonate
Function	Steady-Flash-Close
LEDs	2 (1 each side)
LED color	amber
Battery	NiCad

Resources:

Barricade Lights Flyer

Barricade Lights Instructions

Warning and Barricade Light Variations:

Light Type	Use	Description	Application
Type A	Low-intensity, flashing, typically has 2 lit sides.	Nighttime	Used for warning of hazards at night. They should not be used for guiding traffic since the off/on flashing could be confusing. They are not as visible during the day and may even be off during daylight hours.
Type B	High-intensity, flashing, typically has a hood and faces only one direction so all the light energy is focused in one direction.	24-hour	Used to warn road users during both daylight and nighttime hours.
Type C	Low-intensity, steady burn, typically has 2 lit sides.	Nighttime	Can be used at night to delineate the edge of a roadway and to help guide drivers since they have a constant light. When used to delineate a curve, Type C lights must be used on the outside of the curve, and not on the inside of the curve.
Type D	360° steady-burn lights.	Nighttime	Applications where steady-burn light needs to be seen from all sides, such as airports. When used to delineate a curve, Type D lights must be used on the outside of the curve, and not on the inside of the curve.
