Import Test 2: character check

Each character twice: written as an HTML code, and typed directly. If the two columns match, the character survived the upload.

Code	Character	As HTML code	Typed directly
Plain ASCII (the house rule)
A1	Straight double quote (inches)	["]	["]
A2	Straight apostrophe (feet)	[']	[']
A3	Ampersand	Tom & Jerry	Tom & Jerry
A4	Comma	[,]	[,]
In the site's character set (ISO-8859-1)
B1	Degree sign	[°]	[°]
B2	Registered sign	[®]	[®]
B3	One half	[½]	[½]
B4	One quarter	[¼]	[¼]
B5	Multiplication sign	[×]	[×]
B6	Accented e	[é]	[é]
Windows-only (Word's smart punctuation)
C1	Trademark sign	[™]	[™]
C2	Left curly double quote	[“]	[“]
C3	Right curly double quote	[”]	[”]
C4	Left curly single quote	[‘]	[‘]
C5	Right curly single quote	[’]	[’]
C6	En dash	[–]	[–]
C7	Em dash	[—]	[—]
C8	Ellipsis	[…]	[…]
C9	Bullet	[•]	[•]
Outside both character sets
D1	Double prime (inches)	[″]	["]
D2	Ring above (used as degree)	[˚]	[°]
D3	Full-width plus	[＋]	[+]
D4	Check mark	[✓]	[?]

Underground Detectable Tape (CAUTION BURIED GEOTHERMAL LINE BELOW) - Blue [Import Test 2]

"Caution Buried Geothermal Line Below" detectable underground marking tape provides buried pipeline detection and identification of utility infrastructure. Detectable tapes can protect against costly damage to underground pipelines. The tape consists of .35 mil of solid aluminum foil encased between two layers of polyethylene plastic (3.75 mil combined). A .90 mil clear protective film protects the printed message while allowing a full view of both the foil and printed message. The aluminum foil is visible from both sides of the tape and provides ease in detecting utility lines utilizing either a conductive or inductive method with utility locate equipment.

Features:

Blue color and legend used to mark geothermal lines.
Colors and legends designed in accordance with the APWA National Color Code.
Meets ASTM D-2103, ASTM D-882, ASTM D792-66, and ASTM D2578-08 compliance testing.
Made in USA.

Specifications:

Thickness	5 mil
Foil core thickness	0.35 mil
Tensile	15,000 PSI
Density	1.09 g/cm3

Size Options:

2" x 1000' (6" to 18" maximum recommended burial depth)
3" x 1000' (6" to 28" maximum recommended burial depth)
6" x 1000' (6" to 36" maximum recommended burial depth)
Recommended depths are the maximum depths at which a metal detector will detect any detectable underground tape.

Other Colors & Legends:

Color	Legend
Blue	Caution Buried Water Line Below
Brown	Caution Buried Force Main Line Below
Green	Caution Buried Force Main Line Below
Green	Caution Buried Sewer Line Below
Orange	Caution Buried Fiber Optic Line Below
Orange	Caution Buried Oil Line Below
Red	Caution Buried Electric Line Below
Red	Caution Buried High Voltage Cable Below
Yellow	Caution Buried Gas Line Below

Click a legend to see that tape.

APWA Marking Colors:

Color	Utility Line
White	Proposed Excavation
Pink	Temporary Survey Markings
Red	Electrical Power Lines, Cables, Conduit and Lighting Cables
Yellow	Gas, Oil, Steam, Petroleum or Gaseous Materials
Orange	Communication, Alarm or Signal Lines, Cables or Conduit
Blue	Potable Water
Brown	Non-Potable Water and Force Main Lines
Purple	Reclaimed Water, Irrigation and Slurry Lines
Green	Sewer and Drain Lines

The American Public Works Association, a non-profit professional association, created a uniform color code for utility companies, both public and private. The colors have become the marking standard across all industries.
